● widely used in manufacturing, such as metal manufacturing, chemical, commodity inspection and other measurement fields area
● 2 in1 for steel and aluminum
● adopt high-speed MCU and advanced algorithm to ensure the accuracy and efficiency of measurement
● the instrument supports fast measurement and continuous measurement, and the measurement speed can reach 0.3 s/time
● the wear-resistant metal probe can ensure stable data when measuring on hard or rough surfaces, and the probe wears more than 500,000 times
● small in size, light in weight and easy to carry
● wide measurement range, high precision and good stability, which can meet the measurement of ultra-thin coatings
● automatic power off, Large LCD display, easy to reading
● prime plastic box
| Measuring range: |
0 - 1500 μm |
| Resolution: |
0.1 μm (0 - 99.9 μm), 1 μm (100 - 1500 μm) |
| Accuracy: |
± 2% H+1 μm H = coating thinkness |
| Measurement Mode: |
Single/Continuous |
| Unit Options: |
μm / mil |
| Thinnest Substrate: |
0.3 mm |
| Maximum Curvature: |
convex 5 mm/ concave 25 mm |
| Operating Conditions: |
Temperature: - 10 - 50 °C |
| Humidity: |
0 - 85% RH |
| Power Supply: |
2x AAA Battery (1.5V) |
| Dimensions: |
101x61x26 mm |
| Weight: |
54 g (without Batteries) |
